Temp-6 1960
Sorry, this page is not translated yet. Automatic translation used.
The television receiver of the black-and-white image "Temp-6" and "Temp-7" from I quarter of 1960 produced the Moscow Radio Plant. Televisions '' Temp-6 '' and '' Temp-7 '' embodied the latest achievements of domestic and foreign television technology of the early sixties. They were in no way inferior to the best foreign models, and exceeded them by many parameters. Televisions are created by the design bureau of the Moscow Radio Plant under the direction of DS Hefets. The models are 17 tube 12 channel TVs. The difference in kinescopes and design. In the TV "Temp-6" a 43LK9B kinescope is installed with a beam deflection angle of 110 °. Image size 270x365 mm. In the TV "Temp-7" - 53ЛК6Б, image size 350h470 mm. Televisions have a general scheme, design and characteristics. In the TV "Temp-7" due to a slightly larger case and an improved speaker where one loudspeaker is located in the bottom of the case and the other on the side, the frequency range is 80 ... 8000 Hz, and at the TV "Temp-6" it is 100 .. .7000 Hz, 2 loudspeakers also work in the AU, but they are in front. Rated output power 1 watt. Sensitivity 100 µV. Such sensitivity in combination with the AFC and F and AGC allows you to get a confident reception of programs on an outdoor antenna within a radius of up to 70 km. Power consumption 200 watts. It is possible to connect headphones and sound pickup. There is a PPDU to control the brightness of the image and the volume of the sound (not included). Cases are wooden, veneered with valuable wood species. Dimensions of TV "Temp-6" - 444x562x338 mm. Weight 28 kg. The price of the model is 336 rubles. Dimensions of the TV "Temp-7" - 544x610x442 mm. Weight 43 kg. The price of TV is 480 rubles. Televisions were exported to Europe and America. Over the years of production (1960 ... 1964) of TVs "Temp-6", the plant produced 320,000 copies. Television "Temp-7" was produced 13,500 copies. Since 1962, the Å iauliai Television Factory also produced the TV "Temp-6". At the end of 1964, the TV "Temp-7" was upgraded to the model "Temp-7B", but there was no information about it.
Documentation:
Video:
Information from collection of Valery Khartchenko
