The television receiver for b / w images "Birch-215" since 1976 has been produced by the Kharkov PO "Kommunar".
,86e6f450b8cc469628ba70bf2947b049
Unified TV of the 2nd class `` Beryozka-215 '' (ULPT-61-II-28) provides reception on any channel of the MW range, and when installing the SKD-1 unit, on any channel of the UHF range.
,86e6f450b8cc469628ba70bf2947b049
The model has the ability to remotely control the brightness, volume and mute the speakers, in the presence of a wired remote control.
,86e6f450b8cc469628ba70bf2947b049
It is possible to listen to the sound of broadcasts on the headphones with the loudspeakers on and off.
,86e6f450b8cc469628ba70bf2947b049
The TV uses a 61LKZB kinescope with a screen size of 61 cm diagonally. The speaker has 2 loudspeakers 3GD-38S and 2GD-36.
,86e6f450b8cc469628ba70bf2947b049
The sensitivity of the TV is 50 μV.
,86e6f450b8cc469628ba70bf2947b049
Clarity 500 lines vertically, 450 lines horizontally.
,86e6f450b8cc469628ba70bf2947b049
Maximum output power 2.5W.
,86e6f450b8cc469628ba70bf2947b049
The range of reproducible frequencies is 100 ... 10000 Hz.
,86e6f450b8cc469628ba70bf2947b049
Power consumption 180 watts.
,86e6f450b8cc469628ba70bf2947b049
TV dimensions 685x525x420 mm.
,86e6f450b8cc469628ba70bf2947b049
Weight 36 kg.
