Melodija-104-stereo 1978
Sorry, this page is not translated yet. Automatic translation used.
The network stereophonic block radio "Melodiya-104-stereo" has been produced since 1978 by the Riga Radio Plant. ,86e6f450b8cc469628ba70bf2947b049 A.S. ,86e6f450b8cc469628ba70bf2947b049 Popov. ,86e6f450b8cc469628ba70bf2947b049 It works in the bands DV, CB, 3 sub-bands HF and VHF. ,86e6f450b8cc469628ba70bf2947b049 EPU radio with magnetic head, reproduces gramophone from mono and stereo records. ,86e6f450b8cc469628ba70bf2947b049 In the VHF range, reception is carried out with automatic tuning. ,86e6f450b8cc469628ba70bf2947b049 There is a possibility of fixed tuning for three FM radio stations. ,86e6f450b8cc469628ba70bf2947b049 Radiola has a stepped bandwidth adjustment in the IF of the AM channel, a silent tuning system in the VHF range. ,86e6f450b8cc469628ba70bf2947b049 The band of reproducible sound frequencies in the AM path is 63 ... 6300 Hz, FM 63 ... 12500 Hz. ,86e6f450b8cc469628ba70bf2947b049 Sensitivity in the VHF FM range - 2.5 μV. ,86e6f450b8cc469628ba70bf2947b049 Rated output power 2x6 W. ,86e6f450b8cc469628ba70bf2947b049 Harmonic distortion 4%. ,86e6f450b8cc469628ba70bf2947b049 Power consumption when receiving 46 W, playing a record 50 W. ,86e6f450b8cc469628ba70bf2947b049 Dimensions of the radio receiving unit 168x630x300 mm, EPU 175x455x330 mm, one speaker 157x157x300 mm. ,86e6f450b8cc469628ba70bf2947b049 Kit weight 26 kg. ,86e6f450b8cc469628ba70bf2947b049 Radiola was produced in 3 configuration options. ,86e6f450b8cc469628ba70bf2947b049 ,null,ru,null,null,null,null
Documentation:
Video:
Information from collection of Valery Khartchenko
