Sonata-304 1973
Sorry, this page is not translated yet. Automatic translation used.
The "Sonata-304" reel-to-reel tape recorder has been produced by the Velikie Luki Radio Plant since the 1st quarter of 1973. ,86e6f450b8cc469628ba70bf2947b049 Transistorized four-track tape recorder of the 3rd class "Sonata-304" is developed on the basis of the "Sonata-303" model. ,86e6f450b8cc469628ba70bf2947b049 The tape recorder is designed to use coils # 15. ,86e6f450b8cc469628ba70bf2947b049 The speed of the magnetic tape is 9.53 cm / sec. ,86e6f450b8cc469628ba70bf2947b049 Recording time 4x65 min. ,86e6f450b8cc469628ba70bf2947b049 LPM has a temporary stop of the tape in the working mode, and the clamping of the tape to the heads is replaced by 2 movable columns. ,86e6f450b8cc469628ba70bf2947b049 There are treble and bass tone controls. ,86e6f450b8cc469628ba70bf2947b049 Rated output power 1.5 W, operating frequency range 63 ... 12500 Hz. ,86e6f450b8cc469628ba70bf2947b049 The speaker system consists of 2 loudspeakers 1GD-40. ,86e6f450b8cc469628ba70bf2947b049 Power supply from 220 or 127 V. Power consumption 45 W. ,86e6f450b8cc469628ba70bf2947b049 The dimensions of the MG are 365x290x159 mm. ,86e6f450b8cc469628ba70bf2947b049 Weight 8.5 kg. ,86e6f450b8cc469628ba70bf2947b049 The price is 175 rubles. ,86e6f450b8cc469628ba70bf2947b049 ,null,ru,null,null,null,null
Documentation:
Video:
Information from collection of Valery Khartchenko
