Since the fall of 1957, the network tube radio "Festival" has been produced by the Popov Riga Radio Plant. ,86e6f450b8cc469628ba70bf2947b049In 1957, the documentation of the serial receiver "Leningrad" was transferred to the Riga plant named after Popov, where it received the name "Festival". ,86e6f450b8cc469628ba70bf2947b049By the end of 1957, an experimental batch was released, and in 1958 mass production began. ,86e6f450b8cc469628ba70bf2947b049The superheterodyne receiver of the highest class, with remote control "Festival" is assembled on 12 lamps, with internal antennas, a number of novelties in the circuit and design, with a mechanical AFC and remote control from a wired remote control. ,86e6f450b8cc469628ba70bf2947b049Manual control is usual. ,86e6f450b8cc469628ba70bf2947b049Bass, treble tone control is combined with the IF passband of the AM path. ,86e6f450b8cc469628ba70bf2947b049The model has sockets for external antennas, EPU, tape recorder and additional speakers. ,86e6f450b8cc469628ba70bf2947b049From the remote control at a distance of up to 6 meters, you can carry out all the control of the receiver, except for adjusting the timbres. ,86e6f450b8cc469628ba70bf2947b049The speaker system consists of a front loudspeaker 6GD1, two side wideband 4GD2 and a high-frequency 1GD1. ,86e6f450b8cc469628ba70bf2947b049During the production process, various FM units were used in the receiver, and the HF loudspeaker was located on the front panel on the right or under the woofer. ,86e6f450b8cc469628ba70bf2947b049The case had shades ranging from dark red to light yellow. ,86e6f450b8cc469628ba70bf2947b049The price of the model is 276 rubles. ,86e6f450b8cc469628ba70bf2947b049since 1961. ,86e6f450b8cc469628ba70bf2947b049For 1960, it was planned to release the receiver in a light case, which did not happen. ,86e6f450b8cc469628ba70bf2947b049Wave ranges: DV, SV and VHF-standard. ,86e6f450b8cc469628ba70bf2947b049KV1-49 m, KV2-41 m, KV3-31 m, KV4-25 m. Sensitivity on all ranges 50 µV, on VHF 5 µV. ,86e6f450b8cc469628ba70bf2947b049The intermediate frequency of the AM path is 465 KHz. ,86e6f450b8cc469628ba70bf2947b049FM path 8.4 MHz. ,86e6f450b8cc469628ba70bf2947b049Selectivity on all bands 66 dB, on VHF 34 dB. ,86e6f450b8cc469628ba70bf2947b049The band of reproducible sound frequencies of the AM path is 60 ... 6500 Hz. ,86e6f450b8cc469628ba70bf2947b049FM 60 ... 12000 Hz. ,86e6f450b8cc469628ba70bf2947b049Output power: nominal 4 W, maximum 10 W. ,86e6f450b8cc469628ba70bf2947b049Power consumption 110 watts. ,86e6f450b8cc469628ba70bf2947b049The dimensions of the device are 660x424x311 mm. ,86e6f450b8cc469628ba70bf2947b049Weight 24.5 kg. ,86e6f450b8cc469628ba70bf2947b049The dimensions of the remote control are 222x220x58 mm. ,86e6f450b8cc469628ba70bf2947b049Its weight with cable is 1.75 kg.,86e6f450b8cc469628ba70bf2947b049,null,ru,null,null,null,null
