Epos-001-stereo 1982
Sorry, this page is not translated yet. Automatic translation used.
The electric player "Epos-001-stereo" from I quarter of 1982 was produced by the Moscow Experimental Plant of the Research Institute of Long-Distance Radio Communication. Stereo electric player with direct drive "Epos-001-stereo" is designed to work together with high-quality stereo sound reproduction systems that have a preamplifier. The model is equipped with an ultra-slow engine, with quartz stabilization of the rotational speed. The turnaround of the player is equipped with a downforce stabilizer, which, in combination with an electronic system for creating downforce, anti-skating forces and the presence of static balancing of the arm along its three axes, ensures good pickup contact with the groove of the record. The player uses a Orthofon magnetic head with a diamond needle, which has a crystallographic orientation along the track, also has a microlift and auto-stop, which is triggered by an increase in the speed of the needle moving in the area of "‹"‹the end of the record. Pickup installation is done remotely. The control unit of the player is made on transformer sensors and reed switches, with light indication. The switch works - quasi-touch. The frequency of rotation of the disk 33.33 and 45.11 rev / min. The operating frequency range is 20 ... 20000 Hz. Downforce Pickups 15 mN. Knock factor 0.01%. The relative level of roar -70 dB. The relative background level is -74 dB. The power consumed from the network 8 watts. Dimensions of the electric player 480x408x127 mm. Its weight is 15 kg. The release of the electric player since 1984 - differed from the previous ones by the presence of a patch on the magnets located under the tube of the arm of the arm and there was no inscription - "Electronic control of the arm."
Documentation:
Video:
Information from collection of Valery Khartchenko
